BOY 100 Electric – vollelektrischer Spritzgießautomat für Spitzenleistungen
Dynamics, precision, and parallel movements
The BOY 100 Electric is a state-of-the-art injection molding machine with fully electric drives for injection, plasticizing, and ejection. It delivers outstanding dynamics, highest positioning accuracy, and shortest cycle times – ideal for automation in injection molding and for demanding applications in plastics processing.
Efficiency & Compact Design
With a newly developed universal injection unit including patented back-pressure measurement, the BOY 100 Electric sets new standards among injection molding machine manufacturers. The two-platen clamping unit with oil-free mold area, energy-optimized servo hydraulics, and pressure intensifier or differential pressure technology guarantees maximum performance with the smallest possible footprint – a proven injection molding machine for plastics with future-oriented manufacturing.
Highlights
- Parallel movement without double pump
- Compactness of a two-platen machine
- Highly dynamic injection unit
- Lubricant-free tool installation area
- Improved synchronised movement during ejection
- Parallel clamping force build-up for injection
- Highest positioning accuracy
- Possibility to actively brake
Technical data
- Euromap Size:
800-170 - Screw Diameter:
28, 32, 38, 42 - Max. Stroke Volume:
173.2 cm³ (theoretical) - Max. Injection Flow:
207.8 cm³/s - Max. Spec. Injection Pressure:
2210 bar - Max. Daylight Between Platen:
725 mm - Max. Opening Stroke:
475 mm - Distance Between Tie Bars:
430 x 360 mm
